LPPL040-02A-EN Pneumatic Rotary Unions with Through Bore

share
copy Link
Facebook
Twitter
LinkedIn
Consult immediately
DetailInstallationReview(0)

Description:

A pneumatic rotary unions is a mechanism used to transfer fluid (under pressure or vacuum) from a stationary inlet to a rotating outlet, preserving and isolating the fluid connection.

Pneumatic rotary unions are engineered to endure a wide range of temperatures and pressures for a variety of conditions and environments. In addition, rotary unions may integrate multiple passages and handle different types of fluid simultaneously.



Pneumatic rotary joint

Max. Operating Pressure

0~0.6Mpa

Compression medium

Air

Channel number

2 channel

Working Speed

0~5rpm

Windpope diameterφ6mm
No-load torque≤5 N.m
Inner Diameterφ40mm
Connecting calibreG1/8''
Housing Material

Aluminum Alloy





LPPL040-02A-EN-Outline Drawing
