Through Bore Slip Rings

Number of Circuits 06/12/18/24
Current 5A(Signal)/10A/15A
Insulation Resistance ≥500MΩ@500VDC
Wire Length rotor/stator:300mm
Voltage 240VAC/DC
Consult immediately
DetailInstallationReview(0)

JINPAT Through Bore Slip Rings are also known as Hollow Shaft Slip Rings and Through Hole Slip Rings. These slip ring branch is named because there is a central through hole going through the slip ring unit. The hollow shaft design is to facilitate installation on the shaft of application end or to allow other fluid/gas channels or power leads to pass through.

The through bore design makes through bore slip ring very practical especially in industrial production. The hollow shaft slip ring allows pipelines and electrical channels to pass through. And the slip ring can be easily installed on the robotic arm shaft to help maneuver and connect to different joints of the application.

The through hole diameter is optional from 0 to 1000mm, the slip ring loads power up to 5,000A. JINPAT Hollow Shaft Slip Rings transmit analogue signals, digital signals and power. And since the through hole slip rings are widely applied in the industrial manufacturer section, JINPAT Electronics has upgraded the rotary joint branch to integrate various industrial Ethernet signals like EtherNet , EtherCAT ,ProfiNet, Powerlink , SercosIII/IP, etc.

Aside from letting pipelines and leads to go through the slip ring unit, the hollow shaft structure is also very convenient for integration with other electrical slip rings and rotary joints like radio frequency slip ring, fiber optic rotary joint and hydraulic pneumatic rotary union, etc.

JINPAT Through Bore Slip Rings fit for robots, automated industrial production equipment, large volume medical testing equipment like CT scanner and so on. According the physical requirement of the application end, client can demand certain specifications like through hole diameter, channel numbers, housing material and compatible signals. Our hollow shaft slip rings go through a series of life span tests and performance tests. JINPAT guarantee you a happy experience with our slip ring product. Talk to our JINPAT team to work out a custom solution for you!


LPT Through-bore Slip Rings
Model

ID

(mm)

OD

(mm)

VoltageCurrentLength(mm)

Rotating

Speed

(rmp)

Aluminum

Ring

Diameter

(mm

Rotor

Exposed

Length

(L1)

Width of

Anti

-rotation

Tab(A)

Groove

Width

of Anti-

rotation

Tab(B)

Height

of Anti-

rotation

Tab(H)

Thickness

of Anti

-rotation

Tab(L2)

Details

6

Circuits

12

Circuits

18

Circuits

24

Circuits

LPT012Φ12.7
Φ53240VAC/DC

5A/

Signal

Φ56

5A/

Signal

3447.861.675.4
10A3753.870.687.4
LPT025Φ25.4Φ86240VAC/DC

5A/

Signal

380VAC/DC

10A

47.570.994.3117.7

15A

52.380.5108.7

136.9

LPT038Φ38.1Φ99240VAC/DC

5A/

Signal

380VAC/DC10A47.871.895.8119.8
15A52.681.4110.2139
LPT050Φ50Φ119240VAC/DC

5A/

Signal

10A54.278.2102.2126.2
15A5987.8116.6145.4
LPT060Φ60Φ135240VAC/DC

5A/

Signal

10A56.778.9101.1123.3
15A61.588.5115.5142.5
LPT070
Φ70Φ135240VAC/DC

5A/

Signal

52.570.588.5106.5300Φ95
10A56.778.9101.1123.3
15A61.588.5115.5142.5
LPT080Φ80Φ160240VAC/DC

5A/

Signal

10A64.691.6118.6

145.6

15A67.697.6127.6157.6
LPT096Φ96Φ185240VAC/DC

5A/

Signal

10A6996123150
15A72102132162
LPT120Φ120Φ207240VAC/DC

5A/

Signal

10A81108135150
15A84114144162
LPT150Φ150Φ250240VAC/DC

5A/

Signal

10A98131164197
15A101137173209
LPT180Φ180Φ298240VAC/DC

5A/

Signal

10A104137170203
15A107143179215





LPT   Long Life Slip Rings
ModelID(mm)OD(mm)Length(mm)VoltageCurrent

Rotating

Speed(rmp)

Application

Lifespan

(turns)

Details
LPT009-0204-05SΦ9.55Φ3526.6240VAC/DC

2x4A+5

*common signal

300

or higher

LPT009-1802-HSΦ9.5Φ31.843240V2A/Signal

500

or higher

Turntable Equipment50millions详情.png
LPT010-0602Φ10Φ3624.6240V2A/Signal

300

or higher

Radar Equipment50millions详情.png
LPT012A-1202Φ12.7Φ3534.4240VAC/DC2A/Signal

300

or higher

CableReel Equipment50millions详情.png
LPT012B-0602Φ12.7Φ35.129.6240VAC/DC2A/Signal

300

or higher

Test Equipment50millions详情.png
LPT012B-0602-HS-HTΦ12.7Φ35.129.6240VAC/DC2A/Signal

2000

or higher

High-Speed Railway

Equipment

LPT012-3002-HSΦ12.7Φ3666240V2A/Signal

500

or higher

Turntable Equipment50millions详情.png
LPT032-0802-HS-HTΦ32Φ6141.9220V2A/Signal400

High-Speed Railway

Equipment

SPT050-104-0610Φ50Φ10458.8500V10A400Packaging Equipment50millions详情.png
SPT050-104-1210Φ50Φ10482.8500V10A400Packaging Equipment50millions详情.png
SPT050-104-1810Φ50Φ104106.8500V10A400Packaging Equipment50millions详情.png
SPT050-104-2410Φ50Φ104130.8500V10A400Packaging Equipment50millions详情.png


JINPAT Through Bore Slip Rings Installation Instructions and Illustration


1. The slip ring unit should not bear the load of the connected equipment, nor any external pulling forces.
2. Avoid rigid connection between rotor and stator when install. The 4 screws should be mounted to fix the rotor on the rotation axis. Insert the rod into the anti-rotation tab on the stator side. Meanwhile, make sure the wires are well arranged to avoid intervention and breakage.
3. Slip rings are high precision electronic components. To cope with harsh environment, a custom slip ring solution with higher protection grading is preferable.






Notes for JINPAT LPT Through Bore Slip Ring


1. Please remain intact of the leads during installation. Avoid effect on electronic performances due to wire breakage.
2. Rotor side is connected to the stator side through flexible connection instead of rigid coupling to ensure a longer service life.
3. To avoid looseness and falling of the nails due to impacts and shocks, locking measures are adopted to stabilize the nails.

Comment

comment
name
Praise degree
Message:
Upload pictures:
    total 0 Sheet,Only 5 images can be uploaded, each less than 5m.
    Verification code
    submit
