LPFO optical slip rings are also known as fiber optic rotary joints, optical rotatory connector. The optical slip ring adopts optical fiber as media. It offers the best solution to transmit great capacity data and signals. The optical slip ring can be integrated with traditional electrical slip rings. The hybrid slip ring model is able to transmit power, signals and high speed data.
Specifications | |||
Fiber types | SM or MM | Connector types | F C/SC/ST/LC(PC or APC) |
Channel number | 1 | Estimated life cycle | ＞200 million revolutions |
Wavelength range | SM:1270-1650nm MM:650-1300nm | Vibration | MIL-STD-167-1A |
Insertion loss | ＜2dB | Mechanical shock | MIL-STD-810G |
Insertion loss ripple | ＜0.5dB | IP rating | IP65 or IP68 |
Return loss | ≥40dB | Maximum speed | 2000rpm |
Max Optical power | 23dBm | Working temperature | -45～+80℃ |
Package style | Pigtails on both ends | Storage temperature | -55~+85℃ |
Weight, approx | 10g（No tail cable andconnection included） | Jacket types | 0.9/2/3mm(Kevlar/PVC or Armor) |
