Pancake Slip Ring 12 Circuits with Aluminum Alloy Housing for Robots pcb slip ring
  • JINPAT
  • China
  • 2 weeks
  • 100

LPK series is a group of Pancake Slip Rings manufactured by JINPAT with the thickness as small as 6mm. They are designed exclusively for rotation systems in which installing space is limited in height at vertical direction. Both copper ring and brush contact surround a central hole, which saves space a lot.

LPK series is a group of Pancake Slip Rings manufactured by JINPAT with the thickness as small as 6mm. They are designed exclusively for rotation systems in which installing space is limited in height at vertical direction. Both copper ring and brush contact surround a central hole, which saves space a lot.


Features


High Rotating Speed

Unfailing contact, light figure

Extremely low physical noise

Transmitting power and signal in 360° rotation

No interference or connection drop


Advantages


Ready-made photoelectric encoder

Optional solid and hollow shafts

Rapid delivery

Custom solution


Specification


Electronic & Electric

Mechanical

Circuits

2circuits *6A



Working Speed

0~180rpm

Inner Diameter

Φ200mm

Working Voltage

12V

Contact

Nobel Metal

Dielectric Strength

≥300V@50Hz



Housing

FR-4

Insulation

200MΩ@500VDC

Wire Length

Stator Wire:300mm



Environment

Remarks

Temperature

-20°C~+60°C

Installation Method



PCB board is fixed on the customer's flange



Humidity

≤60%RH


















Main Application


1. Packaging / wrapping machinery
2. Semiconductor handling systems
3. Industrial machinery
4. Exhibit Display machinery
5. Medical equipment
6. Rotary index tables
7. Process control equipment
