LPA000-06200-0618-44S-01A-05L - 200kW ship electric propeller
Features
1、Long life and easy maintenance
2、High rotation precision, excellent transmission performance, stable and reliable operation
3、Diverse form factor to support more installation requirements
Advantages
1、Power can be 3MW, 6MW, 7.5MW, etc.
2、High-power, signal and gas-liquid rotary joint hybrid transmission
3、IP65 protection level
| Electrical & Electronics | Mechanical | Enviromental | |||
Number of circuits | 62CKT | Rotating speed | 0~3rpm | Temperature | -5°C~+45°C |
| Current | 6×200A+6×18A +44× signal +1×gas+5×liquid | Contact material | Precious metal/ copper graphite | Humidity | ≤95%RH |
| Voltage | 440VAC/220VAC /24DAC | Housing material | Stainless steel 304 | Wire length | custom |
Dielectric strength | ≥2500VAC@50Hz ≥500VAC@50Hz (signal) | Wire type | 70mm2 marine shielded cable CBPJP 85-SC/3*2.5mm² Marine cable CBPJP 85-SC/12*0.22mm² Marine cable CBJPJ 85-SC/12*0.22mm² Marine cable CBJPJ 85-SC | Protection Grade | IP65 |
Insulation resistance | ≥500MΩ@1000VDC ≥500MΩ@500VDC (signal) | Others | |||
| Life span | Can be customized | ||||
Outline drawings
