FGCK-P155-2-K12 - Testing / Aviation / Oil Exploration
Features
1、High speed reaches 0~10000/rpm
2、Instantly reach 18000/rpm
3、High temperature use up to 210 ° C
Advantages
1、Using special molding process and super wear resistant materials
2、Solve the influence of vibration and temperature changes on the signal at high speed
3、Simultaneously meet high vibration performance indicators in harsh environments
| Electrical & Electronics | Mechanical | Enviromental | |||
Number of Circuits | 8CKT | Rotating Speed | 0~18000 rpm | Temperature | -55℃~+210℃ |
| Current | 2A | Contact Material | Gold-to-gold | Humidity | ≤60%RH |
| Voltage | 40VAC/DC | Housing Material | Aluminum oxide white | Protection Grade | IP40 |
| Dielectric Strength | ≥500VAC@400Hz | Torque | ≤0.1N*M | Others | |
Insulation Resistance | ≥600MΩ@200VDC | Wire Type | AWG28# | Life Span | Can be customized |
| Electrical Noise | ≤10mΩ | Wire Length | Rotor: 250±5mm Stator: 250±5mm | ||
Outline drawings
