Capsule -high pressure rotary union

Number of Circuits 6
Current 5
Insulation Resistance ≥100MΩ@200VDC
Wire Length Rotor: 250±5mm Stator: 250±5mm
Voltage 0~48VAC/DC
Consult immediately
Parametri
Number of Circuits
6
Current
5
Insulation Resistance
≥100MΩ@200VDC
Wire Length
Rotor: 250±5mm Stator: 250±5mm
Voltage
0~48VAC/DC
Lo so
DetailInstallationReview(0)

LPC-18A-0605-IP68   -Applications

Ships   /   Port Equipment /   Underwater Operations Equipment / Offshore Oil Platforms / Deep Sea Submersibles / Underwater Vehicles


Features

1、High protection grade slip ring is specially developed for underwater, high pressure seabed and various harsh environments

2、High sealing grade, protection grade reaches IP68

3、Stable and reliable


Advantages

1、Support signal and power transmission

2、All stainless steel full seal design, professional sealing program

3、To meet the long-term underwater or corrosive environment, the theoretical value of working water depth is more than 300 meters



Electrical & ElectronicsMechanicalEnviromental

Number of

Circuits

6CKT

Rotating Speed

0~60 rpmTemperature-20℃~+60℃
Current5A

Contact Material

Gold-to-goldHumidity≤60%RH
Voltage0~48VAC/DC

Housing Material

Aluminum alloyProtection GradeIP68

Dielectric Strength

≥200VAC@50HzTorque/Others

Insulation Resistance

≥100MΩ@200VDCWire TypeAWG22#Life SpanCan be customized
Electrical Noise≤35mΩWire Length

Rotor: 250±5mm

Stator: 250±5mm


Outline drawings
