Integrated slip rings, also known as compact slip rings or combined slip rings, offer several advantages compared to traditional slip rings. These advantages are achieved through innovative technologies and design approaches that aim to streamline the transmission of electrical signals and power in rotating systems. Integrated slip rings truly represent a technological advancement that addresses several key challenges in transmitting signals and power within rotating systems. These benefits make them a compelling choice for applications ranging from aerospace and robotics to industrial automation and beyond.
Advantages of Integrated Slip Rings:
| Electronic & Electric | Mechanical | ||
| Tatal | 8 CKT | Working Speed | 0~10rpm |
| Detail | 8×10A | Inner Diameter | / |
| Rating Voltage | 350VAC/DC | Contact Material | Gold To Gold |
| Dielectric Strength | 1000VAC@50Hz | Housing Material | Aluminium Alloy(Black) |
| Insulation Resistance | ≥1000MΩ@1000VDC | Lead Wire Length | Stator:1000mm Rotor:1000mm |
| Environment | Remarks | ||
| Working Temperature | -20°C—+60°C | Electrical Noise | / |
| Working Humidity | ≤60％RH | Other | / |
| IP | IP50 | / | |
| Specifications | |||
| Fiber typer | SM(9/125um) | Return Loss | SM：≥40dB |
| Chanenel Number | 4 | Crosstalk | ≥23dB |
| Wavelength range | SM:1310/1550nm | Max Optical Power | 23dBm |
| Insertion Loss | ＜4dB | Jacket Types | 2mm(Armor) |
| Insertion Loss Ripple | ＜2dB | Connector Types | ST/PC |
Integrated Slip Rings' Advantages:
Space-Saving Design: Integrated slip rings consolidate functions into a single compact unit, saving space and eliminating the need for multiple components. This is especially valuable for tight spaces.
Weight Reduction: By merging functions, integrated slip rings reduce overall weight. This is advantageous in weight-sensitive applications like aerospace and robotics.
Enhanced Dependability: Fewer connections and interfaces in integrated slip rings lower potential failure points, enhancing reliability and reducing maintenance demands.
Simple Installation: Designed for easy setup, integrated slip rings require fewer cables and connections. This eases installation and minimizes errors.
Less Maintenance: Fewer components and connections translate to reduced maintenance. Integrated slip rings often have longer service intervals and need fewer inspections and repairs.
Better Signal Quality: With fewer connections, integrated slip rings offer superior signal quality and minimized signal loss, ensuring robust data and power transmission.
Cost-Effective: Despite potentially higher initial costs due to integration, integrated slip rings usually deliver lower overall ownership costs through reduced maintenance, fewer parts, and improved reliability.
