LPPL06-16A-EN Standard Pneumatic Rotary Unions

Consult immediately
Parameters
I know
DetailInstallationReview(0)

Description:

A pneumatic slip ring is a mechanism used to transfer fluid (under pressure or vacuum) from a stationary inlet to a rotating outlet, preserving and isolating the fluid connection.

Pneumatic slip rings are engineered to endure a wide range of temperatures and pressures for a variety of conditions and environments. In addition, rotary unions may integrate multiple passages and handle different types of fluid simultaneously.


Pneumatic rotary Joint

Max. Operating Pressure

0~1Mpa

Medium Type

Air

Channel number

16 channel

Working Speed

0~100rpm

Windpope diameterφ4mm
No-load torque≤6 N.m
Inner Diameterφ6mm
Housing MaterialAluminum Alloy
Connecting calibre

M5



LPPL06-16A-EN-Outline Drawing
