LPT009-0204-05S-Through-bore Slip Rings

share
copy Link
Facebook
X
LinkedIn
Current 2×4A+5*common signal
Voltage 240VAC/DC
Length(L)(mm) 26.6
Consult immediately
DetailInstallationReview(0)

LPT009-0204-05S-Through-bore Slip Rings

A slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary to a rotating structure. A slip ring is also called a rotary electrical interface, collector, swivel or a commutation. A slip ring can improve system performance by simplifying operations and eliminating damage-prone wires dangling from movable joints.


Electronic & ElectrucMechanical
CircuitsTotal7CKTWorking Speed0~300rpm
Detail2X4A+5Circuits signalInner DiameterΦ9.55mm
Rating Voltage24VContact MaterialPrecious Metal
Dielectric Strength500VAC@50HzHousing MaterialEngineering plastic
Insulation Resistance≥300MΩ@500VDCLead Wire Length

Stator:300mm

Rotor:300mm

EnvironmentRemarks
Working Temperature-20°C~+60°Application/
Working Humidity

≤60%RH

IP
IP54Other/




LPT009-0204-05S-Outline Drawing

0204-05S Slipring.png



Comment

comment
name
Praise degree
Message:
Upload pictures:
    total 0 Sheet,Only 5 images can be uploaded, each less than 5m.
    Verification code
    submit
    Related Products
    JINPAT's Independently Developed Production Equipment
    Provide quality assurance for slip rings!
    • Machining Equipment
    • CNC Test Equipment
    • Environmental Testing Equipment
    • High-Low Temperature Test Equipment
    • Machining Equipment
    • Slip Ring Life Test Equipment
    What is large current slip ring?

    Large current slip ring is a slip rings can transmitting large power/high current from a stationary part to a rotating part, preserving and isolating the electrical connection. Moflon's high current electric slip rings are high performance, low-cost alternatives to electric slip rings. Because they can function as rotary electrical connectors when high current is required, they are especially well suited for use in heating elements.
    Thanks to our unique channeled brush technology, the contact pressure between the slip ring’s brushes and rotor are greatly reduced. This, coupled with multiple brush contact points, greatly extends working life and allows these devices to be used on continuously operating machinery.

    Havn't found standard size of large current slip rings to fit my application?

    1) View "Customized Solutions", you can find more large current slip rings solutions.

    2) Customize your dimension for large current slip rings and Contact us : sales@electricslipring.com
