LPR-2S Series Slip Rings

Number of Circuits 2
Current 2circuits*1~5A
Voltage 240V
Length(L)(mm) φ40*37
Optional Speed / circuit number / current / housing material
Consult immediately
Parameters
Number of Circuits
2
Current
2circuits*1~5A
Voltage
240V
Length(L)(mm)
φ40*37
Optional
Speed / circuit number / current / housing material
I know
DetailInstallationReview(0)

LPR-2S Series Slip Ring

Description

An electrical slip ring is a device used to transfer power and data from a stationary to a rotating structure. Slip rings can provide continuous or intermittent rotation while transmitting power and data - simplifying operation, improving application performance, and eliminating risk of damage to wiring between movable parts.   A slip ring is also called a rotary electrical interface, collector, swivel or a commutator. A slip ring can improve system performance by simplifying operations and eliminate damage prone to wires dangling from movable joints.

LPR-2S Series slip ring provides routing space for hydraulics, pneumatics or a concentric shaft mount. The LPR-2S adopts advanced fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates. In addition, fiber brushes do not require lubrication and produce virtually no wear debris.

Features

◆ Pins connector, convenient for installation

◆ No mercury, environment-friendly design

◆ Silver plated rings are standard. Gold plated optional.

◆ Speed up to 300 rpm continuous

◆ Steel bearings and machined shaft and housing for harsh environment

◆ Collar mounting is standard; flange mounting is optional

◆ Various lead exits are available

◆ Continuous 360°rotation of power or data signals

◆ Sealed unit


Electronic & Electric

Mechanical

Circuits

Total

2 CKT

Working Speed


0~300rpm

Detail

2x5A

Contact Material

Gold to Gold

Rating Voltage

0~240V   AC/DC

Housing Material

Engineering plastics

Dielectric Strength

500VAC@50Hz

Lead Wire Length

Gold plated pin (8mm)

Insulation Resistance

≥500MΩ@500VDC

Dynamic Resistance Fluctuation Value

35MΩ

Environment

Remarks

Working Temperature

-40°C~+80°C

Application

/

Working Humidity

≤60%RH

Other

/

IP

IP40

Note: "P" stands for power, "S" stands for signal.
