LPFO-01N-E fiber optic slip ring

Number of Circuits 1
Wavelength range 850-1650
Insertion loss <0.5dB
Insertion loss ripple <2dB
Return Loss >40
Optional Single can be customized,housing material and driving connector are optional
Consult immediately
Parameters
Number of Circuits
1
Wavelength range
850-1650
Insertion loss
<0.5dB
Insertion loss ripple
<2dB
Return Loss
>40
Optional
Single can be customized,housing material and driving connector are optional
I know
DetailInstallationReview(0)

LPFO optical slip rings are also known as fiber optic rotary joints, optical rotatory connector. The optical slip ring adopts optical fiber as media. It offers the best solution to transmit great capacity data and signals. The optical slip ring can be integrated with traditional electrical slip rings. The hybrid slip ring model is able to transmit power, signals and high speed data.




LPFO-01N-E-fiber optic rotary joints.jpg







Specifications
Fiber typesSM or MMConnector typesFC/SC/ST/LC(PC or APC)
Channel number1Estimated life cycle>200 million revolutions
Wavelength range

SM:1270-1650nm

MM:850-1300nm

VibrationMIL-STD-167-1A
Insertion loss<2dBMechanical shockMIL-STD-810G
Insertion loss ripple<0.5dBIP ratingIP54
Weight, approx/Jacket types0.9/2/3mm(Kevlar/TPU or Armor)
Return lossSM:≥40dBMM:≥30dBMaximum speed2000rpm
Max Optical power23dBmWorking temperature-45~+80℃
Package stylePigtails on both endsStorage temperature-55~+85℃
