Application of JINPAT bus ring in UAV

Application of JINPAT bus ring in UAV

The junction ring is an important node part in the communication and situational awareness equipment such as photoelectric turret, radar antenna, satellite communication antenna and electronic countermeasure antenna in the modern combat system. All kinds of signals and power must be transmitted and returned through the bus ring. With the blessing of artificial intelligence and modern communication technologies, unmanned application systems will gradually begin to appear in various scenarios, such drones are equipped with high-definition video signal integrated bus rings to support the operation of the photoelectric turret.

In addition to drones, unmanned boats and unmanned vehicles with single or multiple functions such as electronic countermeasures, reconnaissance, and attack have also begun to be developed, and products with actual combat capabilities have been developed by major manufacturers. In the unmanned application system, the equipment on the optical detection, electronic countermeasures, communication and other subsystems is almost universal, and these devices are basically no different in technical details except that some structures will be modified according to the different installation platforms, so the bus ring used can basically achieve universal.

JINPAT Electronics, as a leading manufacturer of bushing rings with domestic technical strength, has no problem in meeting the needs of this future unmanned combat platform for bushing rings. Taking the photoelectric turret SDI HD video bus ring as an example, JINPAT products have the ability to transmit 12G-SDI signals.

At present, the use of higher frequency of the bus ring has HD video signal integrated bus ring, photoelectric integrated bus ring, high-frequency integrated bus ring and multi-channel precision bus ring, etc., according to the integrated module function is different, these bus rings will also be installed on the corresponding equipment, such as photoelectric integrated bus ring is not necessarily installed in the photoelectric turret this photoelectric equipment, It is installed in the rotating joint of some important communication equipment to transmit high speed optical signals, power and other signals. If you have the needs of drone bus ring, welcome to contact JINPAT.
