Gigabit Ethernet signal Slip Rings LPT025-0620-08S-E3
share
DetailInstallationReview(0)
LPT025-0620-08S-E3 Through Bole Slip Rings(with gigabit Ethernet channel)
The LPT025-0620-08S-E3 Through Bore Slip Ring supports current and multi-signal channels, including gigabit Ethernet. With precious metal contacts and an IP54 rating, it provides long-lasting durability and reliable operation in challenging conditions. Ideal for automation, robotic arms, and industrial systems, this slip ring combines high-speed data transmission with robust performance.
| Electronic & Electric | Mechanical | |||
| Circuits | Total | 15 | Working Speed | 0~300rpm |
| Detail | 6×20A+5Circuits signal+1× gigabit Ethernet | Inner Diameter | / | |
| Rating Voltage | 380VAC | Contact Material | Precious Metal | |
| Dielectric Strength | Between two channels＞500VAC@50H(P) | Housing Material | Aluminum Alloy | |
| Insulation Resistance | 500MN@500VDC(P) 100MΩ@300VDC(S) | Lead Wire Length | Stator:300mm Rotor:300mm | |
| Environment | Remarks | |||
| Working Temperature | -20°C~+60°C | Application | Automation equipment/robotic arm industrial system | |
| Working Humidity | ≤60%RH | |||
| IP | IP54 | Other | / | |
Havn't found standard size of large current slip rings to fit my application?
1) View "Customized Solutions", you can find more large current slip rings solutions.
2) Customize your dimension for large current slip rings and Contact us : sales@electricslipring.com
