LPM-0217-0213-0205-E2-E3 Dual Ethernet & Power Slip Ring

copy Link

Facebook

Number of Circuits 1*E3+1*E2+2*5A+2*13A+2*17A

Current 5A/13A/17A

Voltage 72V AC/DC

Working Life ≥10 million revolutions

Consult immediately

DetailInstallationReview(0)

LPM-0217-0213-0205-E2-E3 Dual Ethernet & Power Slip Ring

Simultaneously transmit Gigabit (1000M) and Fast Ethernet (100M) signals with integrated power delivery. The military-grade stainless steel housing supports 10M+ rotation cycles, while gold-to-gold contacts ensure <1ns latency for smart grid systems, wind turbines, and automated logistics equipment. JINPAT provides application-specific customization for hybrid signal requirements.

Electronic & Electric			Mechanical
Circuits	Total	1 set * Gigabit Ethernet/1 set * 100Mbps Ethernet/2 * 5A/2 * 13A/2 * 17A	Working Speed	150rpm
	Detail		Contact Material	Gold to Gold
Rating Voltage		72V AC/DC	Housing Material	Stainless steel
Dielectric Strength		≥200VAC@50Hz(P/S)	Lead Wire Length	Stator:250±5mm Rotor:250±5mm
Insulation Resistance		≥10MΩ@200VDC(P/S)	Dynamic Resistance Fluctuation Value	≤35mΩ
Environment			Remarks
Working Temperature		-20°C~+60°C	Application	Customizable
Working Humidity		≤60%RH	Product lifespan	≥10 million revolutions
IP		/	Note: "P" stands for power, "S" stands for signal
