Separate Slip Rings
Separate Slip Rings
We would provide the slip ring(Rotor)and brush block(Stator) as separate components to be mated by customer in their system.It can be used for routing hydraulic lines and pneumatic lines,it is especially fit for minute and precise instruments.
| Part No. | OD(mm) | Circuits | Voltage AC/DC(V) | Current | Operating Speed Max(rpm) | Contact Material |
| LPS-060 | ---- | 3 | 240 | 10A | 0-100 | Precious metal |
Click here to download Spec sheet
| Part No. | OD(mm) | Circuits | Voltage AC/DC(V) | Current | Operating Speed Max(rpm) | Contact Material |
| LPS-12 | ø14.73 | 12 | 240 | 1-3A | 0-100 | Gold to Gold |
| Part No. | OD(mm) | Circuits | Voltage AC/DC(V) | Current | Operating Speed Max(rpm) | Contact Material |
| LPS-06 | ø14.73 | 6 | 240 | 2A | 0-100 | Gold to Gold |
| Part No. | OD(mm) | Circuits | Voltage AC/DC(V) | Current | Operating Speed Max(rpm) | Contact Material |
| LPS-04 | ø3.5 | 4 | 240 | 1-3A | 0-100 | Gold to Gold |
| Part No. | OD(mm) | Circuits | Voltage AC/DC(V) | Current | Operating Speed Max(rpm) | Contact Material |
| LPS-03 | ø2.9 | 3 | 240 | 1-3A | 0-100 | Gold to Gold |
| Part No. | OD(mm) | Circuits | Voltage AC/DC(V) | Current | Operating Speed Max(rpm) | Contact Material |
| LPS-02 | ø28.0 | 2 | 240 | 2A | 0-100 | Gold to Gold |
