The compact size and gold to gold contact make our LPC capsule slip rings  very suitable for small system to transfer signal and data as well as power. 1 circuit to 125 circuits are available.

The color-coded lead wires of miniature slip rings are provided on both the rotor and stator to allow simplified electrical connections. Meanwhile,the gold-gold contact ensures the resistance very low.

Subminiature Capsule Slip Rings---LPMS Series

-Outer diameter:7.9mm, very high precision
-Stainless steel housing and rotating axis, very low torque
--Working temperature could be high to 200 ℃
-All military standard raw materials, which ensures low signal transmitted well in very harsh environment.

We would provide the slip ring(Rotor)and brush block(Stator) as separate components to be mated by customer in their system.It can be used for routing hydraulic lines and pneumatic lines,it is especially fit for minute and precise instruments.

The through bore slip rings is specially designed for through bore hydraulic or pneumatic
rotating shaft installation, different configures of circuits and Amps meet your demand totally Option: Gold plated rings; Flange is optional; Advanced multi-contacting ensures reliable operation with low friction.

Pancake approach is used when length is at a premium but diameter is less restrictive;
Any dimension of through bore or solid is option;
Please contact us, our sales engineers will provide you recommendation or customization.

LPR series high Current slip ring provides routing space for hydraulics, pneumatics or for a concentric shaft mount. It uses our fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates. In addition, fiber brushes do not require lubrication and produce virtually no wear debris.

The mercury slip rings are used for ant kind of rotating objects of signals like micro voltage,
current,EMF,thermo couple,strain gauge,audio,video,high frequency etc and electric power connections.

As electrical slip rings are to electrical signals, Fiber Optic Rotary Joints are to optical signals
-This series covers single mode single channel, single mode multi channel and multi mode multi channel. Optical signal only or hybrid unit(optical+electric) is transmitted.
Capsule and through bore fiber optical rotary joints are available.

It is specially designed for high frequency sliprings signal transmission, the frequency could be high to 2GHz. The LPHF series features precious metal contacts at the rotary interface. Flying lead wires on the rotating side and solder terminals on the stator side complete the electrical connections. Precision ball bearings and the patented fiber brush design allow operation up to 10,000 rpm without the need for cooling equipment.

JINPAT has developed a com-prehensile standard programmed that is able to offer optimum solutions. The standard programmed enables the creation of slip ring bodies of any number of poles up to 100 for power and data/signal currents. Slip ring bodies can be supplied either as open slip ring bodies to be built in customers requirements or in a housing of impact-resistant plastic.

Jinpat's hybrid fiber optic rotary joint is used widely in special applications.Combined design for electric power rings and fiber optic rotary joint could solve the difficult technology for compatibility of high frequency bandwidth and electric power rings.

Power rings integrate single channel or multi channels fiber optic are optional.Such kind of design are extensively used in simulation application.

Advantage
High frequency and bandwidth
Good compatibility for data and power transmitting
Reliable performance and life
High sealing grade is optional




Multi-circuits Slip Ring
- 76circuits is available within compact dimension.
Please contact us, our sales engineers will provide you recommendation or customization.

For typical applications, we have specialized R&D team to design and develop slip rings as per your special requirements, such as high working speed, high protection grade, high frequency, hybrid unit of optical and electrical, high speed data transmission, hydraulic or pneumatic system and so on, design is quickly, delivery time is prompt Please contact us, our sales engineers will provide you recommendation or customization.

High speed slip ring are used in testing application mostly as speed is required up to 10,000 runs or more in such application.Special brush design make the slip ring last long life time without maintenance.


Advantage
Rotation speed are optional
Maintenance free
Lower drive torque
Transfer control signal
Precious metal contact

Available in high current, our High current slip ring is widely used in industry application. Reliable construction design and stable electrical performance is the advantage of the High current slip ring.

Any special spec,contact us and we will provide a completely solution for you.
